項目Item
|
單位 Unit
|
YQ32 -40 /40A
|
YQ32 -63
|
YQ32 -100
|
YQ32 -200 /200A
|
YQ32 -315
|
YQ32 -500 /500C
|
YQ32 -630 /630A
|
YQ32 -800
|
YQ32 -1250
|
YQ32 -2000
|
|
|
公稱力 Nominal Force
|
kN
|
400
|
630
|
1000
|
2000
|
3150
|
5000
|
6300
|
8000
|
12500
|
20000
|
|
|
回程力 Return Force
|
kN
|
180/60
|
190
|
260
|
400
|
630
|
1000
|
1200
|
1200
|
2000
|
4000
|
|
|
頂出力 Knock out Force
|
kN
|
100
|
190
|
190
|
350
|
630
|
1000
|
1000
|
1000
|
2000
|
2500
|
|
|
液體工作壓力 Max pressure of liquid
|
MPa
|
25
|
25
|
25
|
25
|
25
|
25
|
25
|
25
|
a25
|
25
|
|
|
拉伸滑塊行程 Stroke of drawing slide
|
mm
|
450
|
500
|
600
|
700
|
800
|
900
|
1000
|
900
|
700
|
800
|
|
|
頂出活塞行程 Stroke of knock-out cylider
|
mm
|
150
|
150
|
200
|
250
|
300
|
350
|
350
|
350
|
300
|
400
|
|
|
滑塊距工作台距離 Height of table above Floor
|
mm
|
700
|
800
|
900
|
1100 /1000
|
1250
|
1500
|
1800
|
1500
|
1400
|
1400
|
|
|
滑塊行程速度 Speed of slide
|
快下 Rapid down
|
mm/s
|
36/130
|
80
|
100
|
100
|
100
|
100
|
100
|
80
|
80
|
60
|
|
工作 Pressing
|
mm/s
|
18
|
10
|
14
|
18
|
12
|
10
|
6
|
8
|
6-10
|
2-6
|
|
|
回程Return
|
mm/s
|
75/130
|
60
|
80
|
80
|
60
|
80
|
60
|
60
|
45
|
50
|
|
|
頂出行程速度 Speed of knock-out cylider
|
頂出 Knock- out
|
mm/s
|
95
|
50
|
70
|
90
|
55
|
80
|
80
|
60
|
75
|
70
|
|
退回Return
|
mm/s
|
120
|
100
|
140
|
120
|
110
|
160
|
160
|
120
|
100
|
100
|
|
|
工作台有效麵積 Table area
|
左右L-R
|
mm
|
460
|
570
|
720
|
1000 /2000
|
1250
|
1400 /2200
|
1600 /1400
|
1500
|
2200
|
6000
|
|
前後F-B
|
mm
|
460
|
490
|
580
|
900 /1500
|
1120
|
1400
|
1600 /1200
|
1400
|
1800
|
1000
|
|
|
外形尺寸 Overall Dimensions
|
左右L-R
|
mm
|
1385
|
2000
|
2160
|
2825
|
3200
|
4060
|
4200
|
4800
|
5250
|
6000
|
|
前後F-B
|
mm
|
920
|
1500
|
1504
|
2060
|
2500
|
3525
|
4200
|
2200
|
3800
|
2200
|
|
|
地麵以上 Height above floor
|
mm
|
2254
|
2550
|
3150
|
3791
|
4250
|
4995 /5165
|
5615
|
6000
|
6000
|
7550
|
|
|
電機功率 Total power
|
kW
|
7.5
|
7.5
|
7.5/11
|
15
|
22
|
37
|
37
|
45
|
74
|
90
|
|
.
